Technical Specifications
| Nominal Diameter | DN10 To DN3000mm |
| Nominal Pressure | 0.6 to 4.0MPa (Higher Pressure can be customized) |
| Main Power | AC220V 50Hz / DC24V / 3.6V |
| Language | English, Others can be customized. |
| Display | Instantaneous flow, Flow unit, Cumulative flow |
| Unit | Liter, m³, Gallon (Optional). |
| Accuracy | ±0.5%, ±0.3% |
| Output Signal | RS485 / 4 to 20mA / Pulse / Analog |
| Communication | RS232, RS485 (MODBUS), HART is optional |
| Lining Material | Neoprene, Polyurethane Rubber, PTFE, F46, PFA |
| Electrode Material | SUS316, HB, HC, Titanium, Tantalum, Platinum-iridium alloy, Wolfram |
| Medium Temp. | -68 °F to 356 °F (-20 °C to +180 °C) |
| Ambient Temp. | -77 °F to 140 °F (-25 °C to +60 °C) |
| Medium Electrical Conductivity | ≥5us/cm |
| Measuring Range | 1500:1, Flow rate<15m/s |
| Protection Class | IP65, IP67, IP68 (Optional) |
