Overview
Enviro Test Construct thermal imaging thermometer can be used in fields of Car repairing, floor heating maintenance, power box short-circuits detecting, building leakage detecting, electrical product maintenance, firefighting, energy, geology, archaeology, electronic manufacture, etc. It is the ideal selection for electrician, technician, maintenance person and to find the problem area quickly.
Features
- VOX Sensor
- 320 x 240 resolution and 70 mk high sensitivity
- Wide temperature range
Technical Specifications
| Display screen | 3.5 ″ full angle TFT display screen |
| Infrared image resolution | 320 x 240 |
| visible image resolution | 300,000 pixels |
| Field angle/shortest focus length | 56°x 42°/ 0.15 m |
| Emissivity | Adjustable from 0.01 to 1.0 |
| Temperature measurement range | -4 °F to 854 °F (20 ℃ to 450 ℃) |
| Frame rate of thermal images | 9 Hz |
| Wavelength coverage | 8 um to 14 um |
| Focus mode | Fixed |
| View option | The integration of thermal image with 25% step length and visible image. |
| Storage medium | Built-in 3G (above 20 thousand images stored) |
| File format | JPG |
| USB | Micro USB 2.0 |
| Power supply | Built-in rechargeable 26650 battery |
| Automatic power-off time | Selectable: 5 min /20 min / not power off automatically |
| Product size (length × width × height) | 3.82 in x 5.08 in x 10.08 in (97 mm × 129 mm × 256 mm) |
| Relative humidity | <85% RH |
