Features
- Five optional sensors for measuring special shaped work-pieces.
- DSP chip controlled achieves high accuracy and fast testing speed.
- Matrix LCD screen displays all parameters and data.
- 13 parameters: Ra, Ry, Rq, Rz, Rt, RSm, RS, Rp, Rv, R3z, RSk, Rmax, Rmr
- 4 filtering methods: RC, PC-RC, GAUSS and D-P.
- High quality with ISO/ DIN/ CE/ JIS/ FCC standards.
- Memory: 100 groups of measuring data.
- Power supply: 3.7V rechargeable Li-ion battery.
- Available PC software for data management and Excel reports.
- Optional printer connecting by USB.
Technical Specifications
| Measuring range | 0.005 μm to16 μm |
| Resolution | 0.001 μm |
| Maximum driving trip | 0.7 in (17.5 mm) |
| Sample length/Range (L) | 0.009 in (0.25 mm), 0.03 in (0.8 mm), 0.09 in (2.5 mm)/±20μm, ±40μm, ±80μm |
| Evaluation length | 0.04 in (1.25 mm), 0.15 in (4 mm), 0.19 in (5 mm) |
| Filtering methods | RC, PC-RC, GAUSS, D-P, |
| Error of indication | ≤±10% |
| Variation of indication | <6% |
| Memory | 100 Groups |
| Operating temperature | 32 °F to -40 °F (0 °C to -40 °C) |
| Standard configuration | Main Unit, Standard sensor, Calibration block, Supporting platform, Power charger, Manual, Certificate, PC analysis software |
| Optional Accessories | Measurement Platforms, optional sensors, printer |
| Dimensions | 4.68 in x 1.85 in x 2.55 in (119 mm × 47 mm × 65 mm) |
| Weight | 0.97 lb (440 g) |
