Overview
Enviro Test Construct special calibrator for temperature gauge is a controlled source of thermal radiation used to calibrate infrared radiation thermometers (pyrometers), thermal imagers and radiation heat flux gauges and radiometers. It is manufactured product which is special used in calibration for Infrared ear temperature gun, forehead temperature gun and medical thermometer. It can also be used for the calibration of infrared body surface screening instrument.
Features
- More than 0.99, isothermal black body cavity
- Only one cavity mouth, cavity mouth radiation evenly distributed with the spectrum
- Novel design, simple operation
- Adapt automatic temperature control method, safe and reliable
- Fast temperature rise and good temperature stability
- Easy to operate, small size and light weight, easy to carry
- Suitable not only for laboratory calibration, but also for field calibration
- Display the measured value, set value and parameter setting with double row digits
- New technology, high precision, multi – function and strong anti – interference ability
Technical Specifications
| Temp Resolution | 32.01 °F (0.01 °C) |
| Cavity Diameter | Φ2.20 in (56 mm) |
| Cavity Depth | 1.97 in (50 mm) |
| Emissivity | ≥0.99 |
| Temp Stability | ±32.18 °F (±0.1 °C) / 30 min |
| Temp Uniformity | ±32.18 °F (±0.1 °C) |
| Power | 220 V AC 50 Hz |
| Measure Range | 86 °F to 122 °F (30 °C to 50 °C) |
| Weight | 6.61 lb (3 Kg) |
