Overview
Enviro Test Construct Sound Pressure Meter is occurred in the measurement of ultrasonic cleaning tank of the intensity of ultrasonic measuring instruments (pressure). The measuring instrument is measuring the instantaneous value of ultrasonic cleaning machine wash force and average designed for the development of portable sound pressure meter, the ultrasonic irradiation in the cleaning fluid at the surface of the fluid surrounding the pressure as ultrasonic cleaning machine wash are determined by a net force. Can be used to detect ultrasonic intensity distribution in ultrasonic cleaning tank, ultrasonic cleaning machine ultrasonic device, such as the adjustment of examination, the wash effect of management, industrial parts, and the analysis ultrasonic irradiation intensity and wash effect, etc.
Features
• This measuring instrument operation is simple and accurate
• Holding a lithium battery
• Color screen display, real-time computation
• Can be continuous 48 hours data memory, data upload.
• This product is to provide independent software (to buy)
• Customer special requirement (custom)
Technical Specifications
| Model | OKS-SYJ100 |
| Measuring Range | 0 w/in2 to 255 w/in2 |
| Frequency | 10 kHz to 100 kHz |
| Data Display | Color screen display, time and energy curve, the maximum, minimum, average, record file number |
| Data Storage | Time, instantaneous energy, continuous recording 24 hours, 180 k data (0.5 seconds per point) |
| Power | 3.7 V li-ion rechargeable battery |
| Material | Stainless steel tube |
| Frequency Display | No |
| Data Upload | No |
| Fluid Temperature | 32 °F to 302 °F (0 ℃ to 150 ℃) |
| Meter Diameter | 0.39 in (10 mm) |
| Length | 39.37 in (1.0 m) ; 19.68 in (0.5 m) stainless steel probe +19.68 in (0.5 m) cable |
