Features
- Automatic voltage identification
- Peak power tracking
- Compatible battery
- Pure sine wave
- Large LCD screen
- High conversion rate
Technical Specifications
| Input Voltage | AC 230 V PV max 150 V |
| Output Voltage | 230 V plus or minus 5 % |
| Output Current | 40 A |
| Output Frequency | 50 Hz or 60 HZ |
| Output Type | Single |
| Type | DC and AC Inverters |
| Inverter Efficiency | 98 % |
| Battery Voltage | 12 V or 24 V |
| Transfer Time | 10 minutes or 20 minutes |
| Maximum PV Array Power | 550 W (12 V) or 1100 W (24 V) |
| MPPT Range At Operating Voltage | 20 to 150 at 30 to 150 |
| Surge Power | 2000 V or 3000 V |
| Operating Temperature | 14 °F to 122 °F (- 10 ℃ to 50 ℃) |
| Size | 11.81 in x 9.25 in x 3.54 in (30 cm x 23.5 cm x 9 cm) |
| Weight | 8.82 lb (4 kg) |
