Features
- Meets the GLP requirements of international norms
- Standard with 7801 glass sodium ion electrodes
- Standard with 6212 type double salt bridge reference electrode
- KCI solution in the inner chamber
- Self setting two calibration solutions
- Four units of ion concentration measurement can be freely switched
- Intelligent stirrer as standard
Technical Specifications
| Measuring Range(mV or ORP or EM) | -1999.9 mV to 0 mV to 1999.9 mV |
| Resolution | 0.1 mV |
| Accuracy | ±0.03% FS |
| Measuring Range Ion Concentration | pH: (0.00 pH to 14.00 pH) pNa: Supporting facilities: (1.00pNa to 7.00 pNa) |
| Display Unit | pX, mol/L, mg/L, ppm |
| Accuracy | PH: ±0.01 pXSupporting facilities: ±0.02 pX |
| Data Storage Other Technical Parameters | 900 sets |
| Storage Content | Measurement value number, measurement value, temperaturevalue, ATC or MTC status, measurement date, measurement time |
| Power Supply | DC9 V or 300 mA |
| Communication Interface | RS 232 |
| Ambient Humidity Working Conditions | ≤75% |
| IP Rating | IP54 dust proof and splash proof |
| Temperature Compensation Range | 32 °F to 140 °F (0 °C to 60 ℃) (automatic or manual) |
| Measuring Range Temperature | 14 °F to 230 °F(-10 ℃ to 110 ℃ |
| Resolution | 0.1°C or 0.1 °F |
| Accuracy | 41 °F to 140 °F (5 ℃ to 60 ℃) range: 0.4 °F (± 0.4 ℃) Otherranges: 0.8 °F (± 0.8 ℃) |
| Ambient Temperature | 41 °F to 95 °F (5 °C to 35 ℃) (0.01 level) 59 °F to 86 °F (15 ℃to 30 ℃) (0.001 level) |
| Dimension | 6.29 in x 7.48 in x 2.75 in (160 mm x 190 mm × 70 mm) |
| Weight | 1.94 lb (0.88 kg) |
