Overview
Enviro Test Construct’s smart digital meter is reliable and accurate humidity temperature meter with the measuring humidity range of 0 to 100%RH by using a new developed humidity sensor. Wall-mounting type separated type and insertion type are prepared for various applications. Heat-resistive separated type is available for using in the environment of -40 to 356°F. TES temperature and humidity testers combine precise, accurate measurement of temperature and humidity to save time and steps. Measure and monitor temperature and relative humidity measurements over time using an TES temperature and humidity data logger.
Features
- LCD displays temperature and humidity.
- Dew point and Wet temperature reading.
- Absolute humidity, mixing ratio and Enthalpy reading.
- Water vapor pressure and water saturation pressure reading.
- Pressure trend and tendency reading.
- Heat Index and Humidex reading.
- MAX/MIN with Time Stamp.
- Alarm output function.
- Auto power off function.
- Data hold function to hold the LCD reading.
Technical Specifications
| Features | Dual LCD displays Temperature & Humidity |
| Measurement range (Humidity) | 1%RH to 99%RH |
| Measurement range (Temperature) | -4°F to 140°F(-20°C to 60°C) |
| Resolution (Humidity) | 0.1%RH |
| Resolution (Temperature) | 0.1°C/0.1°F |
| Accuracy (Humidity) | ±3%RH (@77°F(25°C), 20 to 80% RH) ±4%RH (@77°F(25°C), 10 to 20% RH and 80 to 90%RH) |
| Accuracy (Temperature) | ±0.8°F(@ 41°F to 140°F) ±1.6°F(@ -4°F to 41°F and 140°F to 176°F)(±0.4°C(@ +5°C to 60°C) ±0.8°C(@-20°C to 5°C and 60°C to 80°C)) |
| Data Memory capacity | Manual recording: 99 data sets. (Direct reading from LCD display.) |
| Sampling Rate | 1 times/s |
| Operating Conditions | 32°F to 140°F (0°C to 60°C) & below 99% R.H. |
| Power Source | 9V Battery |
| Battery Life | Approximately 300 h |
| Accessories | Instruction manual Battery |
| Size | 7.59843x 2.32283x 1.02362 in (193x59x26mm) |
| Weight | 0.308647lb(140g) |
