Technical Specifications
| DC V | Range 0 V to 60.000 V (Upper Display ±30 V) Accuracy 0.02%+2 0.05%+2 |
| DC mA | Range 0 mA to 24 mA (Upper Display ±24 mV) Accuracy 0.02%+2 0.05%+2 |
| DC mV | Range 0 mV to 15 mV to 80 mV 80 mV to 125 mV Accuracy 0.02%+2 0.05%+2 |
| Resistance (2 Wires, 3 Wires) | Range 0 Ω to 440 Ω 400 Ω to 3200 Ω Accuracy 0.15 Ω 1.0 Ω 0.25 Ω 1.5 Ω |
| Resistance (4 Wires) | Range 0 Ω to 440 Ω 400 Ω to 3200 Ω Accuracy 0.1 Ω 0.5 Ω 0.15 Ω 1.0 Ω |
| Frequency | Range 1 Hz to 99.99 Hz 1000 Hz to 9999.99 Hz 10 kHz to 99.99 kHz Accuracy 0.01%+1 0.02%+1 |
| RTD | Pt100, Pt1000, Cu50, Cu100 |
| Power Supply | 24 V DC |
| Operating Temperature | 14 °F to 131 °F ( -10 °C to 55 °C) |
| Storage Temperature | -4 °F to 140 °F ( -20 ℃ to 60 ℃) |
| Relative Humidity | 0% to 90% |
| Dimension | 7.78 in x 3.77 in x 1.85 in (200 mm x 96 mm x 47 mm) |
| Weight | 1.43 lb (650 g) |
