Features
- Smart cleaning
- Comes with intelligent device with automatic cleaning function
- Sensitive response, wide detection range
- Can be used for low turbidity detection. (<1NTU, with flow slot)
- Multiple output methods
- Support MODBUS / RS485 4-20mA current interface output to facilitate system integration.
- Temperature compensation function
- Built-in temperature sensor with temperature compensation function makes measurement more accurate
Technical Specifications
| Measuring range | 0 NTU to 200 NTU |
| Resolution | 0.01 NTU ,0.1 NTU ,1.0 NTU |
| Accuracy | ±0.2 NTU or ±5 % |
| Operating temperature | 5 ℃ to 40 ℃ |
| Analog interface | 4 to 20 mA |
| powered by | 12 V DC±20% |
| calibration | One point or two point |
| Protection class | Ip68 |
| size | Φ54*150 mm |
| temperature range | -10 ℃ to 50 ℃ |
| Cable length | 5 m |
| Texture | 316 stainless steel |
