Features
- 1 to 5 points calibration
- Automatic calibration solution recognition
- Selectable cell constant
- Normalization temperature
- TDS conversion factor
- Seawater and practical salinity measurement modes
- Linear or pure water compensation
- Automatic Temperature Compensation
- Ensures accurate reading
- Calibration Due Reminder
- Prompts user to calibrate the meter regularly
- Stability indicator automatically
- Shows current measurement status
- Auto-Hold function freezes
- Stable measured value
- Selectable temperature unit
- Meets different application requirements
- Automatic electrode diagnosis
- Shows cell constant of the conductivity electrode
Technical Specifications
| Conductivity Range | 0 μS/cm to 20 μS/cm, 200 μS/cm, 2000 μS/cm, 20 mS/cm, 200mS/cm |
| Conductivity Accuracy | ±0.5 % F. S |
| TDS Range | 0 ppt to 100 ppt (Max. 200 ppt, depending on factor setting) |
| TDS Accuracy | ±1 % F. S |
| Salinity Range | 0 ppt to 1O ppt (Max. 80 ppt) |
| Salinity Accuracy | ±1% F. S |
| Resistivity Range | 0 MΩ to 100 MΩ |
| Resistivity Accuracy | ±1% F. S |
| Calibration Points | 1 point to 5 points |
| Calibration Solutions | 10 μS/cm, 84 μS/cm, 1413 μS/cm, 12.88 mS/cm, 111.8 mS/cm |
| Memory | Stores up to 500 data sets, USB Communication Interface |
| Cell Constant | K=0.1, 1, 10 or User-defined |
| Power Requirements | 3 M.5 V “AA” batteries (Standard) or DC 5 V power adapter (Optional) |
| Temperature Compensation | 32 °F to 212 °F (0 °C to 100°C), Manual or Automatic |
| Temperature Coefficient | 32 %/°F to 50 %/°F (0.0 %/°C to 10.0%/°C) |
| Normalization Temperature | 68 °F or 77 °F (20°C or 25°C)) |
| Dimension | 6.69 in x 3.35 in x 1.18 in (170 mm x 85 mm x 30 mm) |
| Net Weight | 0.66 lb. (300 gm) |
