Overview
Enviro Test Construct rugged data collectors are specialized mobile computing devices designed to withstand harsh environmental conditions and demanding usage in industrial settings. These tablets are engineered to endure extreme temperatures, moisture, dust, vibration, and sometimes even shock. They are commonly used across various industries like manufacturing, logistics, field services, construction, healthcare, and more. Most rugged tablets have a high IP (Ingress Protection) rating, indicating their resistance to dust and water. An IP rating like IP65 or higher is common, offering protection against water jets and dust ingress. The screens are designed to offer good readability even in bright sunlight, ensuring visibility in outdoor or high-glare conditions. Some may feature anti-glare or sunlight-readable displays.
Technical Specifications
| Display | Gorilla Glass 3 9H 5.0 in. T FT-LCD (720 x 1280) touch screen with backlight | |
| Backlight | LED backlight | |
| Keypads | 3 TP keys, 6 function keys, 4 side buttons | |
| Expansions | 2 PSAM, 1 SIM, 1 TF | |
| Battery | Rechargeable li-ion polymer, 3.7V, 4500m (about 2.8 mi) Ah | |
| CPU | Quad A53 1.3GHz quad-core | |
| Operating System | Android 7.0 | |
| Storage | 2GB RAM, 16GB ROM, Micros D (max 32GB expansion) | |
| Humidity | 5%RH to 95%RH (non-condensing) | |
| Drop Specifications | 5ft./1.5 m (drop to concrete across the operating temperature range) | |
| Sealing | IP65, IEC compliance | |
| ESD | ±15kv air discharge, ±8kv direct discharge | |
| SDK | Handheld-Wireless Software Development Kit | |
| Language | Java | |
| Environment | Android Studio or Eclipse | |
| WWAN | TDD-LTE Band 38, 39, 40, 41; FDD-LTE Band 1, 2, 3, 4, 7, 17, 20; | |
| WCDMA (850/1900/2100MHz); | ||
| GSM/GPRS/Edge (850/900/1800/1900MHz); | ||
| WLAN | 2.4GHz/5.8GHz Dual Frequency, IEEE 802.11 a/b/g/n | |
| WPAN | Blue tooth Class v2.1+EDR, Blue tooth v3.0+HS, Blue tooth v4.0 | |
| GPS | GPS (embedded A-GPS), accuracy of 5 m | |
| 1D Bar Code | 1D laser engine | Symbol SE955 |
| Symbol | All major 1D barcodes | |
| 2D Bar Code | 2D CMOS Imager | Honeywell N6603/Newland EM3396 |
| Symbol | PDF417, MicroPDF417, Composite, RSS, TLC-39, Datamatix, QR code, Micro QR code, Aztec, Maxi Code, Postal Codes, US PostNet, US. Planet, UK Postal, Australian Postal, Japan Postal, Dutch Postal. etc. | |
| Resolution | 8.0 megapixel | |
| Lens | Auto-focus with LED flash | |
| RFID LF | Frequency | 125KHz/134.2KHz (FDX-B/HDX) |
| Protocol | ISO 11784&11785 | |
| R/W Range | 2cm (about 0.79 in) to 10 cm (about 3.94 in) | |
| RFID HF/NFC | Frequency | 13.56MHz |
| Protocol | ISO 14443A&15693 | |
| R/W Range | 2cm (about 0.79 in) to 8cm (about 3.15 in) | |
| RFID UHF | Frequency | 865 to 868MHz or 920 to 925MHz |
| Protocol | EPC C1 GEN2/ISO 18000 – 6C | |
| Antenna Gain | Circular antenna(2dBi) | |
| R/W Range | 1 m to 1.5 m (tags and environment dependent) | |
| Sensor | TCS1xx | |
| Sensor Type | Capacitive, area sensor | |
| Resolution | 508 DPI | |
| Performance | FRR<0.008%, FAR<0.005% | |
| Capacity | 1000 | |
| Protocol | ISO 7816 | |
| Baud rate | 9600, 19200, 38400,43000, 56000, 57600, 115200 | |
| Slot | 2 slots(maximum) | |
| Standard | 1xPower Supply; 1xLithium Polymer Battery; 1xDC charging cable; 1xUSB data cable | |
| Operating Temp | -20℃ to 50℃ ( -4 °F to 122 °F) | |
| Storage Temp | -20℃ to 70℃ ( -4 °F to 158 °F ) | |
| Dimension | 6.69 in x 3.34 in x 0.90 in | |
| Weight | 370 g (0.815lb) (including battery wrist strap) | |
