Name: Enviro Test Construct Resistivity Tester Conductivity Meter -
SKU: ETCOHM-128

Technical specification

Monitor	HD LCD display
Display digits	6 bits
Resistivity	10 µΩ.cm to 200 kΩ.cm
Square resistance	50 µΩ / sq to 1 MΩ / sq
Analog resistance	10 µΩ to 200 kΩ
Precision	Resistivity, square resistance: 4%; analog resistance: 0.1%;
Range mode	Automatic, keep
Measuring speed	Fast: 10 times/sec, medium speed: 5 times/sec, slow speed: 2 times/sec
Trigger mode	Internal, manual, external
Sorting function	Built-in comparators: qualified, super and under super
Signal	Qualified, unqualified, closed
Interface configuration	interface or HANDLER or USB Device (optional)
Operating environment	32 °F to 104 °F (0 ℃ to 40 ℃), ≤90% RH
Guaranteed accuracy environment	73.4 °F to 41 °F (23 °C to 5 °C), ≤80% R H
Power requirement	198 V to 242 V (AC), 47.5 Hz to 63 Hz
Power consumption	≤30 VA
Size and weight	Frequency: 50 Hz Max power: 15 VA
Sizes	13.1 in x 4.7 in x 12.5 in (335 mm x 120 mm x 320 mm)
Weight	12.1 lb (5.5 kg)
