Overview
Enviro Test Construct Professional Industrial Portable Conductivity Tester integrated with online chloride ion sensor uses an iron-selective electrode with a solid membrane for testing free chlorine ions in water, making it fast, simple, accurate and economical. In this manual, the technical parameters, communication protocol, operation and maintenance of the chloride ion sensor are introduced
Features
- offers a wide measuring range of 0 μS/cm to 5000 μS/cm for precise conductivity measurement
- It provides a high-resolution display with 1 μS/cm conductivity
- Operating efficiently in a wide temperature and a low-pressure environment
- It accommodates a versatile power supply of 12 VDC to 24 VDC
- Constructed with durable materials including ABS, POM
- The submersion mount design with a ¾ NPT pipe thread makes installation easy
- Comes with a 5-meter cable, with customizable cable lengths available
- Equipped with automatic temperature compensation (Pt 1000) for accurate measurements
- Allows for two-point calibration, ensuring precision in conductivity reading
Technical specifications
| Measuring range | 0 μS/cm to 5000 μS/cm |
| Resolution | 1 μS/cm,32.18 ℉ (0.1 ℃) |
| Precision | ±1.5% F.S.±0.54 ℉ (±0.3 ℃) |
| Working Temperature | 32 °F to 149 °F 0 ℃ to 65 ℃ |
| Working Pressure | < 87 PSI (< 600 kPa) |
| Power supply | 12 V DC to 24 V DC |
| Signal output | RS-485(Modbus/RTU) 、4 mA to 20 mA |
| Wetted Material | ABS and POM and 316L stainless steel |
| Installation Method | Submersion Mount, ¾ NPT Pipe Thread |
| Cable length | 5 meters, other lengths can be customized |
| Temperature compensation | Automatic temperature compensation (Pt 1000) |
| Calibration | Two-point calibration |
| Power consumption | 0.2 W @ 12 V |
| Protection Grade | IP 68 |
