Overview
Enviro Test Construct Portable Turbidimeter is a compact and portable device designed for measuring turbidity in various applications. With its portable design, it allows for convenient on-site testing and transportation. The device offers accurate and reliable turbidity measurements, making it suitable for water quality assessment and environmental monitoring. The user-friendly interface ensures easy operation, and the compact size makes it ideal for fieldwork.
Features
- Compact and portable design for convenient on-site testing and transportation.
- Accurate and reliable turbidity measurements for water quality assessment.
- User-friendly interface for easy operation.
- Suitable for various applications including environmental monitoring and research.
- Durable construction for long-lasting performance.
- Wide measurement range to accommodate different turbidity levels.
- Quick and efficient testing for improved productivity.
- Battery-powered for portable and remote use.
- Data storage and retrieval options for record-keeping and analysis.
- Compliance with industry standards for accurate and consistent measurements.
- Additional features may include calibration options, compatibility with accessories or software, and advanced measurement functions.
- Ideal for fieldwork and situations where portability is important.
Technical Specifications
| Accuracy | ± 2 % of reading plus stray light |
| Battery Requirements | 4, AA |
| Certifications | CE certified |
| Compliance Certifications | CE/WEEE |
| Data Logging | 500 records |
| Display Type | Graphic LCD |
| Enclosure Rating | IP67 |
| Interface | No USB and Power Cord |
| Light Source | Tungsten Filament Lamp |
| Max. operating humidity | 90 |
| Measurement Method | Ratio turbidimetric determination using a primary nephelometric light scatter signal (90°) and transmitted light scatter signal |
| Measurement Modes | Normal (Push to Read), Signal Averaging, Rapidly Settling Turbidity |
| Operating Temperature Range | 30 – 122ºF (0 – 50 °C) |
| Power Requirements | 100 – 240 V AC / 50/60 Hz (with optional Power or USB + Power module) |
| Power Requirements (Hz) | 50/60 Hz |
| Power Requirements (Voltage) | 100 – 240 VAC |
| Power Supply | Batteries (see Battery Requirements) or Optional Power Supply |
| Range | 0 – 1000 |
| Range 2 | NTU |
| Reading Modes | Normal (Push to Read) Signal Averaging Rapidly Setting Turbidity |
| Regulatory | EPA Method 180.1 |
| Repeatability | ± 1 % of reading or 0.01 NTU, whichever is greater |
| Response Time | 6 s in normal reading mode |
| Sample Cell Compatibility | 0.98 in x 2.36 in (25 mm x 60 mm) round |
| Sample Requirements | 0.5 oz (15 mL) |
| Sample Volume | 0.5 oz (15 mL) |
| Signal Averaging | Selectable on/off |
| Source Lamp | Tungsten filament lamp |
| Storage Conditions | -40 ºF to 140 ºF (-40 °C to 60 °C) |
| Stray Light | < 0.02 NTU |
| Units | NTU |
| User Interface | Button Graphic User Interface |
| Dimensions (H x W x D) | 3.03 in x 4.21 in x 9.02 in (77 mm x 107 mm x 229 mm) |
| Display Size | 9.45 in x 6.30 in (240 mm x 160 mm) pixels |
| Weight | 1.17Kg (0.53 kg) without batteries |
