Overview
Enviro Test Construct portable pressure and temperature calibrator is a handheld, battery-powered instrument that measures and sources a variety of parameters. It can be widely applied in industrial fields and laboratories.
Features
- A split-screen display
- Counting pulse function
- Calibration functions
- Auto ramping and auto stepping
- Manual and automatic cold junction compensating
- Clear function
- Temperature unit switching
- Auto flashing jacks
- Backlight LCD
- Battery gauge
Technical Specifications
| V DC | 0 V to 30 V | 0 V to 20 V | 0 V to 10 V |
| mV DC | 0 mV to 100 mV | 0 mV to 100 mV | 0 mV to 100 mV |
| mA DC | 0 mA to 24 mA | 0 mA to 24 mA | |
| Current loop | 0 mA to 24mA | ||
| Transmitter signal | 0 mA to 24 mA | ||
| Counting pulse | 0 to 99999 | ||
| Frequency | 1 Hz to10 kHz | 1 Hz to 5 kHz | |
| Resistance | 0 Ω to 3200 Ω | 15 Ω to 3200 Ω | |
| TC (Thermocouple) | J, K, T, E, R, S, B, N | ||
| RTD (Resistance- Temperature Detector) | Cu50 Pt 100 (385) | ||
