Technical specification
| Measuring range | 1 μ Ω to 1999 μ Ω |
| Resolution | 1 μ Ω |
| Test current | DC 0 to 100 A Continuous adjustable |
| Accuracy | 0.5 % ± 1 d |
| Display | Current: three and a half LCD |
| Resistance: three and a half LCD | |
| Power supply | AC 220 V ± 10 % 50 Hz |
| Measured current | DC 100 A |
| Display | Three and a half LCD |
| Input voltage | AC 220 V ± 10 % |
| Working environment | Temperature 14°F to 104°F (- 10 ℃ to 40 ℃)humidity: ≤80%RH |
| Dimension | 11.8 in x 10.6 in x 7.9 in (300 mm × 270 mm × 200 mm) |
| Weight | 11.02 lb (5 kg) (excluding attachments) |
