Features
- V / ß+ y /a+ ß+ X-ray measurement rotation selection on
- LCD backlit LCD
- Setup function setting key
- Data storage record key
- Unit cumulative count and timing measurement keys
- Measurement switch button
- Confirm button
- Exit button
- Battery measurement and parameter setting keys
- Pulse counting measurement unit switch button
Technical Specifications
| Type Of Measuring Ray | a, β, Y and X-rays |
| Measuring Range (Automatic Range Selection) | Radiation dose rate 0.01 sv / h to 1000 sv / h |
| Pulse dose rate 0 cpm to 4000 cpm, 0 cps to 4000 cps | |
| Cumulative radiation dose 0001 sv to 9999 sv | |
| Cumulative value of pulse dose 0 to 9999 | |
| Sensitivity | 108 pulses or 1000 cpm / mr / hr under the background of cobalt-60 Ray environment with an energy of 1 sv / h |
| Alpha ray from 4.0 MV | |
| Beta ray from 0.2 MV | |
| Gamma-ray from 0.02 MV | |
| X-ray from 0.02 MV | |
| Accuracy | < 10% (below 500 sv / h) < 20% (above 600 sv / h) |
| Ray Selector Switch | Yes, β YX ray for combination selection |
| Sensor | Halogen fill detector (GM Geiger counter) |
| Output Port | Bluetooth wireless data transmission (space transmission distance 32.81 ft (10 m)) |
| Average Time | Manually or automatically adjustable between 2 and 120 seconds |
| Display | Large screen 4-digit digital LCD with bar graph display can display the following data radiation dose rate, pulse dose rate cumulative radiation dose value cumulative pulse dose value time date, alarm value maximum radiation dose rate radiation type measurement dynamic icon instrument internal battery power indication, etc. |
| Alarm Function | The alarm value can be set freely, and the default setting is 5 μ Sv / hr |
| Normal Natural Environment Radiation | Less than 0 usv / h to 0.2 usv / h |
| Value Storage Function | It can automatically store 4000 data and record a set of data every minute (including real-time date, time, measurement value and measurement unit) |
| Bluetooth Data Transfer | 1 set of data is transmitted every second (including real-time data, time measurement value, and measurement unit) |
| Software | Data real-time remote transmission display analysis and recording |
| Power Supply | Four 1.5 V “AA” alkaline batteries |
| Quality Certification | European CE, US FCC-15 |
| Detector Operating Temperature | 32.00 °F to 122.00 °F (0 °C to 50 °C) |
| Size | 7.87 in x 2.75 in x 1.77 in (200 mm x 40 mm x 70 mm) |
| Weight | 0.45 lb (206 g) |
