Features
- Large LCD displays all functions and parameters
- Test at any angle, even upside down
- Supports direct HB value for forged steel
- Wide measuring range for all metallic materials
- Seven auto-identifying impact devices available
- Large memory stores 600 groups of data
- Set upper/lower limits with automatic alarms
- Battery info shows capacity and charge status
- User calibration for enhanced accuracy
- USB port with PC data processing software
- High-speed thermal printer for immediate printing
- NI to MH rechargeable battery
Technical Specifications
| Measuring Range | HLD (170 to 960), HRC (17.9 to 69.5), HB (19 to 683), HV (80 to 1042), HS (30.6 to 102.6), HRA (59.1 to 88), HRB (13.5 to 101.7) |
| Impact Directions | Up, down, horizontal, slanting up, slanting down |
| Standards | ASTM A 956, DIN 50156 to 1, GB or T 17394 to 1998 |
| Hardness Scales | HL, HB, HRB, HRC, HRA, HV, HS. |
| Tensile Strenght | 374 N/m to 2652 N/m 2 |
| Display | 128 x 64 digital matrix LCD |
| Memory | 600 groups max. (relative to impact times 32 to 1) |
| Work Voltage | 9 V or 500 mA |
