Features
- 5 inch high-definition color screen
- Multi-gas test, display mode switch (used for multi-gas)
- Flexible and adjustable pumping system
- Multi-layer filter
- Multiple gas display units
- Powerful, more user-friendly operation
Technical Specifications
| Gas Detected | Carbon monoxide CO |
| Detection Principle | Electrochemical principles |
| Measure Range | 0 to 500、1000、2000 ppm (other optional range 0 to 5000 or 10000 ppm, 0 to 20 or 50 or 100 ppm, 0 to 10 or 50 or 100% Vol) |
| Resolution | 1 ppm |
| Precision | 2% FS |
| Sampling Method | Built-in stable flow pump, flow range: 0 to 500 ML/Min |
| Modular Structure | Can detect up to 1 to 4 kinds of gases |
| Concentration Unit | ppm, mg/m3, %VOL, %LEL, can be switched by one button |
| Display | 3.5-inch color display, resolution 320 x 480 |
| Display Mode | Multiple display modes select-able: multi-channel data mode, multi-curve mode, single channel + single curve mode |
| Data Storage | Standard 16M capacity storage function, can save up to 100000 groups of data. Can be directly connected to the computer through USB, quickly download stored data, EXCEL format |
| Wireless Transmission | (Optional) Bluetooth (with printer), ZigBee, built-in DTU wireless module (optional) |
| Built-in printer or external Bluetooth printer (optional with extra charge) | |
| Operating Language | Chinese and English |
| Battery Capacity | 3800 mA rechargeable |
| Charging Interface | USB charging interface, 5 V or 2 A standard charger |
| Filter Device | Equipped with a multi-layer filter to efficiently filter oil, water and dust. |
| Wireless Network | Bluetooth (with print function), ZigBee, Lora+ (relay DTU), DTU (optional with extra charge) |
| Network Frequency | Lora (470 M), DTU (2.4 G) (optional with extra charge) |
| Wireless Trans. Distance | Lora 0.99 mi (1.6 km), DTU (unlimited) (optional with extra charge) |
| Response Time | ≤ 8 S |
| Repeatability | ≤ ± 1% |
| Zero Shift | ≤ ± 1% (F.S / Year) |
| Working Humidity | 0 to 95% RH (no condensation) (high humidity can be selected with filter drying device) |
| Explosion-Proof | Exic II CT3, GC |
| Alarm Mode | Buzzer, LED and alarm status prompt on the display, fault alarm, pump abnormal alarm, battery low battery alarm, shutdown alarm, fall alarm (optional with extra charge) |
| Recovery Time | ≤ 10 S |
| Linearity Error | ≤ ± 1% |
| Degree Of Protection | IP66 |
| Standard Accessories | Manual, warranty card, power charger, carrying case, water and oil filter, data cable |
| Optional Accessories | Bluetooth printer, pressure sensor, high temperature rod, Metal extension rod, Bendable rod, Silicone hose, dry filter device, PC download software |
| Operating Temperature | -68 °F to 122 °F (20 °C to 50 °C) (optional flue gas sampling probe, up to [1.112 °F, 2.160 °F (600 °C, 1200 °C smoke concentration] |
| Dimensions | 10.6 in x 2.95 in x 1.61 in (270 mm x 75 mm x 41 mm) |
| Weight | 0.89 lb (400 g) |
