Technical Specifications:
| Testing Direction | Highly accurate in any impact direction |
| Testing range | 170 HLD to 960 HLD, 17.9 HRC to 69.5 HRC, 19 HB to 683 HB, 80 HV to 1042 HV, 30.6 HS to 102.6 HS, 59.1 HRA to 88 HRA, 13.5 HRB to 101.7 HRB |
| Hardness standards | HL, HV, HRA, HRC, HRB, HB, HV, HS |
| Applicable materials | Steel and cast steel, alloy tool steel, stainless steel, grey cast iron, nodular cast iron, cast aluminium alloy, copper zinc alloys (brass), an alloy of copper and tin, copper (bronze) |
| Repeatability value | HLD: 0.8% (800 HLD) |
| Resolution | 128 x 64 OLED Display |
| Power supply | Rechargeable lithium battery |
| Working hours | About 10 hrs |
| Operating temperature | 50 ℉ to 122 ℉ (10 ℃ to 50 ℃) |
| Storage Temperature | -22 ℉ to 140 ℉ (-30 ℃ to 60 ℃) |
| Humidity | 90% max |
| Dimensions | 5.8 in x 1.57 in x 1.18 in (148 mm x 40 mm x 30 mm) |
