Technical Specification
| DC Resistance Range | 0.0001 Ω to 30.00K Ω Accuracy ±1% rdg ±5dgt |
| Resistance Resolution | 0.0001 Ω |
| Test Method | Four-wire test |
| Test Current | ≥1 A |
| Open Circuit Voltage | ≤7 V |
| Capacity Factor | Measuring capacity factor≤15 W |
| DC Voltage Range | 0.0 V to 1000 V DC Accuracy ±1.5% rdg ±5dgt |
| DC Voltage Resolution | 0.1 V |
| AC Voltage Range | 0.0 V to 750 V AC Accuracy ±1.5% rdg ±3 dgt |
| AC Voltage Resolution | 0.1 V |
| Power | DC 6 V 4.5 Ah Large-capacity battery Continuous standby for more than 100 hours |
| Backlight | Controllable gray screen backlight, suitable for use in dim places |
| Display Mode | 4-bit large LCD display, gray screen backlight |
| Communication Line | USB Communication Line 1PC |
| Power Consumption | Standby: 30 mA Max (backlight off) |
| Working Temperature | 14°F to 104°F (- 10 ℃ to 40 ℃) |
| Instrument Size | 10.91 in x 8.97 in x 6.02 in (277.2 mm × 227.5 mm × 153 mm) |
| Weight | 5.3 lb (2397 g) |
