Features
- Color High contrast LCD touchscreen
- Intelligent operation system provides features including user management
- Multi-reading feature allows auto-read, timed-read and continuous-read
- Automatic/Manual temperature compensation ensures accurate results
- Auto-hold features senses and locks the measurement endpoint
- Data Storage 1000 sets for each parameter (GLP-compliant)
- Data analysis feature helps user review and recalculate results
- Support for USB communication
- Auto-power off feature
- Reset feature automatically resumes all settings back to default
- IP65 waterproof
Technical Specification
| pH | |
| Range | -2.000 pH to 20.000 pH |
| Resolution | 0.1 pH, 0.01 pH, 0.001 pH |
| Accuracy | ±0.002 pH |
| Calibration Points | Up to 8 |
| Standard Customization | Yes |
| Calibration Reminder | Yes |
| Standard Recognition | USA, NIST, MERK, JIS, GB and DIN buffers |
| mV | |
| Slope Limit | Yes |
| Range | -2000.00 mV to 2000.00 mV |
| Resolution | 0.1 mV, 0.01 mV |
| ORP | |
| Accuracy | ±0.1 mV or ±0.03% |
| EH ORP Mode | Yes |
| Temperature | |
| ORP Calibration Points | 1 custom point (relative mV) |
| Range | 14 ºF to 275 ºF (-10 ºC to 135 ºC) |
| Unit | ºC, ºF |
| Resolution | 0.1 |
| Measurement | |
| Accuracy | ±0.1 |
| Reading Mode | Auto Read (Fast, Medium, Slow), Timed, Continuous |
| Reading Prompts | Reading, Stable, Locked |
| Data management | |
| Temp. Compensation | ATC, MTC |
| Data Storage | 1000 Groups |
| Inputs | |
| GLP Features | Yes |
| pH Electrode | BNC(Q9) |
| Outputs | |
| Temp. Probe | 4-pin aviation connector |
| USB | USB 2.0 flash memory device, PC, scanner |
| Display options | |
| RS232 | Printer |
| Backlight | Yes |
| Auto Shutdown | 300 sec, 600 sec, 1200 sec, 1800 sec, 3600 sec. of |
| General | |
| IP Rating | IP65 |
| Power | Rechargeable Lithium battery, AC Adapter, 100 V AC to 240 V AC input, DC 5 V output |
| Dimensions | 3.54 in x 10.04 in x 1.57 in (90 mm × 255 mm × 40 mm) |
| Weight | 1.1 lb (500 g) |
