Features
- High-voltage insulation resistance tester, 5 range: 500 V to 10000 V, up to 10 TΩ
- Designed according to safety standards
- Insulation resistance range 10TΩ at 10 KV
- Adjustable short circuit current, max 5 mA (or 10 mA by order)
- Automatic display of PI, DAR, leakage current and capacitance
- Superior anti-jamming performance, accurate even with 2 mA interference current
- Rapid capacitive discharge, no manual discharge needed
- 2 power methods: lithium-ion batteries, up to 4 hrs battery life
- Insulation resistance simulation column
- Digital filtering function, reduce external influence deviation
- Perfect protection function, spare fuse prompt function
Technical specification
| Display Type | Digital Only |
| Measuring Range | 15 KV 15 T ohm megohmmeter |
| Testing Voltage | 11 KV digital megohmmeter |
| Accuracy Class | ±(3 % + 5) |
| Operating Temperature | T: 73.4 °F ±41 °F (23 °C ± 5 °C), RH: 45% to 75% |
| Product name | Digital High Voltage 15 KV Megohm Meter |
| Application | Electric Test Kit Insulation Resistance Measurement |
| Function | Insulation Resistance Test, PI and DAR test |
| Power supply | AC 220 V 50 Hz or 60 Hz; 16.8 V Lithium-ion rechargeable battery |
| Voltage Test Range | with 5 range: 500 V, 1000 V, 2500 V, 5000 V, 10000 V |
| Resistance Test Range | up to 15 T ohm |
| Short Circuit Current | 5 mA |
| Safety Standard | IEC 61010-1 safety standards |
| Display | Digital Display |
| Dimensions | 10.2 in x 7.8 in x 6.2 in (26 cm x 20 cm x 16 cm) |
| Weight | 6.6 lb (3 kg) |
