Overview
Enviro Test Construct magnetostrictice level sensor is a adopts advanced magnetostrictive technology and digital electronic technology design, the main processor (CPU) uses high frequency arithmetic processor, circuit design uses high precision instrument to amplify circuit, real digital communications, can accurately measure the oil level, water level, lpg gas level,density and multi-temperature of the tank. It has high precision of measurement parameters, complete data, strong anti-interference ability, strong environmental adaptability, reliable data security, advanced algorithm and so on.
Technical Specification
| The standard connect | 6 probes (max is 12) |
| Six language | English, Chinese, Spanish, Portuguese, French, Mongolian, |
| Explosive proof | Yes |
| Display | LED |
| Output | Modbus |
| Measuring Range | 23.62 in to 157.48 in (600 mm to 4000 mm) |
| Customized Support | OEM, ODM |
| Level range | 85.43 in x 124.80 in (2170 mm to 3170 mm) (OEM) |
| Medium | Gasoline, diesel, kerosene, ethanol ,water etc. |
| Max Communication Distance | 47.24 in (1200 m) |
| Power Supply | 240 V |
| Types | Straight; Flexible |
| Material | Stainless steel 316 |
| Accuracy | 0.02 in (0.5 mm) |
| Wire | With 4.92 ft (1.5 m) (customized) |
| Explosive proof | Yes |
| Connect with console | RS 485 |
