Overview
Enviro Test Construct infrared thermal imaging machine traditional infrared thermometers can only measure single temperature points. This thermal imager can detect temperature variations of an area through a 2.4 in LCD display. Its dual lasers can quickly lock in measurement area and display target temperature. The standard package also includes an 8 GB Micro SD card for image and temperature data storage. Its image blending feature can combine infrared and normal camera images together, allowing in-depth display for areas of interest.
Features
- Dual lasers that lock in measurement area
- LCD display
- Micro SD card for data storage
- Image blending feature
- 2600 mAh Li-ion battery
Technical Specification
| Basic Accuracy | ±35.6 °F (±2 °C) / ±2% |
| D:S Ratio | 20: 01 |
| Response Time | 250 ms |
| Pixel Size | 669.29 µin (17 μm) |
| Image Modes | Thermal, Thermal Blending, Digital Camera |
| Palettes | Iron, rainbow, grey |
| Blending Setup | 0% (Pure infrared), 25%, 50%, 75%, 100% (Pure visible) |
| Spectral Range | 314.96 µin to 551.18 µin (8 µm to 14 μm) |
| FOV | 51° horizontal |
| IFOV | 11 mrad |
| NETD | -459.661 °F (-273.145 °C) |
| Image Frequency | =<9 Hz |
| Saved Image Format | BMP |
| Visible Light Camera | 2 megapixels |
| Display | 2.4-in TFT LCD |
| Display Resolution | 320 pixels x 240 pixels |
| Power | Li-ion battery (2600 mAh) |
| Display Colors | Red and grey |
| Temperature Range | -22 °F to 752 °F (-30 °C to 400 °C) |
| Size | 8.07 in x 4.88 in x 2.55 in (205 mm x 124 mm x 65 mm) |
| Weight | 0.81 lb (370 g) |
