Features
- Fully automatic opening and closing hatch open transparent window.It can prevent the influence of lifting the cover by human.
- 7 inch high-definition intelligent touch screen real-time dynamic curve analysis, direct display of moisture percentage dry weight percentage dry weight.
- High bright halogen lamp. Limit heating temperature is 30 ℃.
- Importedpolymer materials high temperature resistant molding.
- Double motor drive double fan design.
- Intelligent dual temperature control multi-layer stainless steel heating chamber.
- Four layers of stainless steel heated inner cabin to improve the efficiency.
- Removable test cover, convenient for replacement of accessories.
- Intelligent anti pinch and automatic detection opening function to effectively protect the user and the mechanical system of the instrument.
- Fast system update and upgrade.
Technical Specifications
| Range (g) | 210g |
| Readability(g) | 0.001g |
| Operating Temp | 5℃ to 35℃ |
| Pan Size | Ø100 mm |
| Heat Source | Halogen Lamp |
| Temp Sensor | PT 100 |
| Temp Range | 40 ℃ to 230 ℃ |
| Temp Step | 1℃ |
| Moisture Range | 0.00% to 100.00% |
| Moisture Readability | 0.01% |
| Dry Residual Range | 100.00% to 0.00% |
| Dry Residual Readability | 0.01% |
| ATRO | 100% to999% |
| ATRO | 0% to 999% |
| Temp Setting | 40℃-230℃ By 1℃ Step |
| Time Setting | 1 to 99min by 10 s |
| Number Of Storage | 20 |
| Number Of History | 20 |
| Heater | 220V ±15% 50HZ, 110V±15% 60HZ, 400W |
| Balance | Input 220 V 50 HZ,110V 60HZ Output 9V |
| Machine (Dual-drive) | Input: 220V 50HZ,110V 60HZ Output:24V |
| Host Dimension | 215 mm x 195 mm x 415 mm |
| Indicator Dimension | 200X75X135mm |
| Operation Height | 275mm |
| The Chamber Height | 35mm |
| Display | 7 inch touch panel |
| Interface | RS232,RJ45,USB |
