Overview
Enviro Test Construct hygrometer humidity moisture analyzer operation is simple, easy to observe and with its excellent performance is fully used in food, tobacco, pharmaceutical, oil, paper making, feed, chemical industry, coating, mining, environmental protection, geology and other industries for rapid determination of moisture content of material, at the same time meet the solid, particles, powder, gel body and liquid moisture content measurement requirements.
Features
- Fast and uniform halogen lamp heater with innovative SRA technology
- High accuracy
- Heater temperature calibration, MS, MX only
- Measurement procedures, measurement results storage function
- Standard RS 232 interface Communicate with PC or connect to printer
- Large screen fluorescence display with clear and easy to observe
Technical Specifications
| Sensor type | SHS sensor |
| Weighing scale | 2.50 oz (71 g) |
| Weighing accuracy | 0.000004 oz (0.0001 g) |
| Humidity display accuracy | 0.001%, 0.01%, 0.1% |
| Humidity accuracy | >0.035 oz (1 g), 0.05% >0.18 oz (5 g), 0.01% |
| Heater technology | Halogen lamp, straight tube, Max 400 W, 5000 hours |
| Measuring program | 20 groups |
| Measuring way | Standard, automatic comparison, timing, manual |
| Humidity display mode | Relative humidity, absolute humidity, dry wet ratio, wet dry ratio |
| Display type | Large screen fluorescence display |
| Connector | RS 232 |
| Data storage function | 100 groups |
| GLP, GMP, ISO | Standard function |
| Self-checking function | Standard |
| Power | AC 100 V to 120 V or AC 200 V to 240 V, 50Hz, 60 Hz about 400 W |
| Drying temperature | 86 ℉ to 392 ℉ (30 ℃ to 200 ℃) |
| Operate temperature | 41 ℉ to 104 ℉ (5 ℃ to 40 ℃) |
| Operate humidity | Less than 85% RH |
| Sample tray size | Diameter 3.35 in (85 mm), optional 4.33 in (110 mm) |
| External dimensions | 8.46 in × 12.60 in × 6.81 in (215 mm × 320 mm × 173 mm) |
| Weight | About 13.23 lb (6 kg) |
