Overview
Enviro Test Construct high precision temperature process calibrator is a high-precision thermal meter and process signal meter calibrator. Applied to calibrate process signal calibrators, industrial sensors, transmitters etc. Can reach class 0.003 and can calibrate the process signal calibrator of class 0.01 or below.
Features
- DC voltage output 10 mV to 110 V
- DC current measurement 0.1 mA to 110 mA
- DC resistance simulation 4 Ω to 4.4 k Ω
- Simulation and measurement of 11 types RTD
- 12 types of TC
- Voltage or current accuracy class 0.003
- Auxiliary power supply 24 V loop mode
- Power channels have good electrical isolation
- Electrical protection
- AC or DC analog output function (optional)
Technical Specifications
| Power Supply | AC 220 V ±22 V, 50 Hz ±2 Hz |
| Accuracy | Class 0.003 |
| DCV Output or Measurement | 10 mV to 110 V |
| DCI Output or Measurement | 0.1 mA to 110 mA |
| DC Resistance Simulation or Measurement | 4 Ω to 4.4 k Ω |
| RTD | 11 Types |
| Thermocouples | 12 Types |
| Working humidity | <80% 86 °F (30 °C), <70% 104 °F (40 °C), <40% 122 °F (50 °C) |
| Storage humidity | (20% to 80%) RH, non-condensing |
| Interface | RS 232 |
| Working temperature | 32 °F to 113 °F (0 °C to 45 °C) |
| Storage temperature | -4 °F to 158 °F (-20 °C to 70 °C) |
