Features
- Touch screen measuring 7 in
- Door that operates automatically/Window with transparency
- Halogen lamp that stands out/Highlighted halogen lamp
- Materials made of polymer/Heat-resistant molding
- Drive powered by two motors/Design featuring dual fan
- Chamber made of stainless steel for control
- Dynamic curve displayed in real-time/Date and time indicator
- Set temperature and time
- Moisture content percentage measurement
- Save past configurations/history of settings stored
- Establish connection with PC and printer
- Choice between a printer or USB option
Technical Specifications
| Capacitive | 3.88 oz to 7.4 oz (110 g or 210 g) |
| Readability | 0.00003 oz (0.001 g) |
| Heatin source | Halogen lamp |
| Temp. sensor | PT100 |
| Moisture range | 0.009% to 100% |
| Moisture readability | 0.01% |
| Dry range | 100% to 0% |
| Dry readability | 0.01% |
| Time setting | 1 min to 99 min by 1 s |
| Heater | 220 V ± 15% 50 Hz/110 V ± 15% 60 Hz/400 W |
| Balance | Input 220V 50 Hz/110 V 60 Hz Output 9 V |
| Machine | Input 220 V 50 Hz/110 V 60 Hz Output 24V Dual drive |
| Display | 7 in touch panel |
| Interface | RS232(standard) RJ45/USB (optional) |
| Operating temperature | 41 °F to 95 °F (5 °C to 35 °C) |
| Temperature range | 104 °F to 446 °F (40 °C to 230 °C) |
| Temperature step | 33.8 °F (1 °C) |
| Operation Height | 10.82 in (275 mm) |
| The Chamber Heigh | 1.37 in (35 mm) |
| Host Dimension | 8.46 in x 7.67 in x 16.33 in (215 mm x 195 mm x 415 mm) |
| Indicator Dimension | 7.87 in x 2.95 in x 5.31 in (200 mm x75 mm x 135 mm) |
| Weight | 16.53 lb (7.5 kg) |
