Overview
Enviro Test Construct Gloss Meter features is a precision instrument used to measure the glossiness of various surfaces. It provides accurate and reliable gloss readings, making it suitable for a wide range of applications in industries such as automotive, coatings, plastics, furniture, and more.
Features
- In accordance with international standards: ASTMD523, ASTMD1455, ASTMC346, ASTMC584, ASTMD2457, DIN ENISO2813, DIN67530, ENISO7668, JISZ8741, MFT30064, TAPPIT480, GB9754, GB/T13891, GB7706, and GB8807
- Technical parameters conform with JJG696-2002
- Accurate measurement with good repeatability
- Small in size and easy to carry
- Auto calibration feature Intelligent design for rapid measurement
- Can store 254 groups of measurements
- Built-in lithium-ion rechargeable battery
- Backlight display for low-light environments
- USB/RS-232 data output to connect with PC
- Provides data output choices
Technical Specifications
| Display | 4 Digits Backlit LCD |
| Measuring Angle | 20/60º |
| Range | 0.1 to 200 GU |
| Gloss Units | GU |
| Accuracy | ±1.0 GU |
| Resolution | 0.1 |
| Repeatability | ±0.5 GU |
| Measuring Area | 0.27 in x 0.55 in (7 mm x14 mm) (Ellipse) |
| Data Memorized | 254 Groups |
| Operating Conditions | Temperature: 32 °F to 104 °F (0 °C to 40 °C) Humidity:<85%RH |
| Power Supply | 4 x 1.5 V AAA Size (UM-4) Battery |
| Dimensions (H x W x D) | Main Unit: 6.14 in x 2.63 in x 1.10 in (156 mm x 67 mm x 28 mm); Probe: 2.28 in x 1.10 in x 4.25 in (58 mm x 28 mm x 108 mm) |
| Weight | 0.41 lb (190 g) (Not Including Batteries) |
| Standard Accessories | Main Unit Holder with Calibration Standard AC Adapter Optical Cleaning Cloth Carrying Case(B04) Operation Manual |
