Overview
Enviro Test Construct Food and Beverage Industries Turbidity Sensor scattering method is based on a combination of infrared absorption, and infrared light emitted by the light source after the scattering of turbidity in the sample. Finally, by the photodetector conversion value of electrical signals, and obtaining the turbidity of the sample after the analog and digital signal processing.
Technical Specifications
| Measuring Range | 0 to 100 NTU, 0 to 4000 NTU |
| Temperature Range | 32 to 122 ° F (0 to 50 ℃) |
| Accuracy | Less than the measured value of ±1%， or ±0.1 NTU， choose the big one |
| Pressure Range | 58.0 Psi (≤0.4 Mpa) |
| Current Speed | ≤2.5 m/s、8.2 ft/s |
| Calibration | Sample calibration, slope calibration |
| Power Supply | 12 V |
| Communication Interface | MODBUS RS485 |
| Size | 2.36 in × 10.07 in |
| Weight | 3.63 lb (1.65 kg) |
