Features
- Module type design,
- Sensor module can be replaced,
- Display module,
- Output signal board module,
- Main electric board module.
Technical Specifications
| Working Power | DC 24 V (Other power supply please contact us for solutions) |
| Detection Range | As per gas type (combustible gas, toxic gas and oxygen) |
| Output Signal | (4 to 20) mA or Digital signal |
| Relay | Yes, two passive output relay output. (AC 220 V 3 A) |
| Display | LED display |
| EX Grade | Ex db IIC T6 Gb, ATEX, SIL and CNEX certificate is obtained |
| Alarm Value | 1st alarm as per gas type |
| Working Current | ≤ 50 Ma |
| Protection Class | IP66 |
| Transmition Distance | <= 0.62 mi (1000 m) |
| Respond Time | T 90 < 30 s |
| Working Temperature | -40 F to 158 F (-40 ℃ to 70℃) |
| Weight | 2.64 lb (1.2 kg) |
