Overview
Enviro Test Construct environmental radiation emanometer measure radon concentration in ambient air, soil and water and radon exhalation rate in soil and building materials. It can be applied in geological prospecting, radiation protection, nuclear accident monitoring, radiation dose assessment, earthquake prediction and teaching, etc.
Features
- Small size, light weight, suitable to carry
- High sensitivity, low power consumption, AC or DC double use
- With USB data transfer interface, equipped with a Bluetooth printer
Technical Specifications
| Sensitivity | ≥ 0.68 cpm/[Bq•m-3] |
| Background Counting Rate | ≤ 0.3cpm |
| Measuring Range | Radon in air: 3 Bq/ m³ to 100000 Bq/ m³ Radon in soil: 300 Bq/ m³ to 300000 Bq/ m³ Radon in water: 0.003 Bq/L to 100 Bq/LRadon exhalation rate: 0.001 Bq/[m2•s] to 10.000 Bq/[m2•s] |
| Repeatability Measuring Errors | ≤ 5% (Radon chamber concentration is 2000 Bq/m3, environmental relative humidity is 65%, temperature is 77°F (25 °C)) |
| Long-Term Stability | ≤ 10% (8 h) |
| Power Supply | Lithium-ion rechargeable battery/AC, DC power can support the instrument to work continuously for 30 h |
| Operating Environment | Temperature: 14 °F to 104 °F (-10 °C to +40 °C) Relative Humidity: ≤ 90% (104 °F (40°C)) |
| Detector | Combination system of ZnS (Ag) and photomultiplier tube |
| Data Storage | 2000 sets of data |
| Operating Mode | Single measurement or continuous monitoring |
| Monitor | LCD display |
| Way To Take Gas | Active pump-priming |
| Response Time | Radon in air: 30 min Radon in soil: 11 min Radon in water 31 min Radon exhalation rate: 30 min |
| The Host Print Data Format | Date, time, number and radon concentration |
| Dimensions | 13 in x 8.27 in x 6.7 in (330 mm × 210 mm × 170 mm) |
| Weight | 11 lb (5 kg) |
