Overview
Enviro Test Construct Digital Portable Conductivity Tester is a kind of eddy current electrical conductivity tester, which is designed for quick & convenient measurement of material property, such as material separate, quality control, material state check and so on. It uses the electromagnetism testing principle. Testing objects focuses on non-ferromagnetic material.
Features
- The meter uses 60 KHz (aviation industry standard) to inspirit, and the testing data can be read in two kinds of unit: %IACS or MS/m
- Its big typeface, the back light illumination designs are advantageous for users to take the testing data even in low light condition
- Two kinds of operate languages satisfy different national demand
- It uses the high property battery to make sure it keeps more running time, and because of its mini size, it is easy to carry and to grasp hold
- The design of the meter is more advantages: user can replace the probe in the outdoor, don’t need to return to the company to adjust the probe into matching the meter
- It can store 1000 measurement data
Technical Specification
| Measurement technology | Eddy Current |
| Operating frequency | 240 x 320 px TFT-LCD |
| Conductivity Standard Block | Verify and guarantee temperature compensation |
| Measuring range | Conductivity: 6.9% IACS to 110%IACS (4.0 MS/m to 64 MS/m) Resistivity: Correspond to conductivity |
| Distinguishing rate | 0.01% IACS (MS/m) |
| Probe compensated | 0.5 mm |
| Data Storage | Can store 1000 measurements data |
| Measuring accuracy | ±0.1% to ±0.5% IACS |
| Probe diameter | 12 mm |
| Relative humidity | 0 to 95% |
| Temperature range | 32 °F to +122 °F (0 ℃ to +50 ℃) |
| Dimension | 7.08 in x 3.14 in x 1.18 in (180 mm x 80 mm x 30 mm) |
| Weight | 0.57 lb (260 g) |
