Features
- New interface style
- Plug and play USB
- 2 channels
- 7 in (17.78 cm) display
- Automatic measurement
- Unique waveform record
- USB drive system software upgrade
Technical Specification
| Bandwidth | 100 MHz |
| Sample Rate | 1 GS/s |
| Rise Time | ≤3.5 ns |
| Memory Depth | 25 kpts |
| Vertical Sensitivity | 1 mV/div to 20 V/div |
| Time Base Range | 2 ns/div to 50 s/div |
| Display | 7 in (17.78 cm) |
| Display Resolution | 800 pixels x 400 pixels |
| Power | 100 V AC to 240 V AC, 45 Hz to 440 Hz |
| Dimensions | 12.04 in x 5.78 in x 4.80 in (306 mm x 147 mm x 122 mm) |
| Weight | 4.85 lb (2.2 kg) |
