Overview
Enviro Test Construct Digital Non-Ferrous Metal Conductivity Tester, is designed for quick & convenient measurement of material property, such as material separate, quality control, and material state check and so on. It uses the electromagnetism testing principle. Testing objects focuses on non-ferromagnetic material.
Features
- Operates at 60 KHz with data displayed in % IACS or MS/m
- Large font and backlight for low-light conditions
- Dual language support for international users
- Long-lasting high-capacity battery for extended usage
- Compact and portable design for easy handling
- User-friendly probe replacement without factory adjustment
- Ample data storage for up to 1000 measurements
- Multilingual support for diverse users
- Extended battery life for prolonged operation
Technical Specifications
| Operating Frequency | 60 KHz to 120 KHz |
| Display Screen | 240×320 pixels TFT-LCD |
| Instrument Case | Anti-intense impact, waterproof polyester; Toolbox |
| Temperature Compensation | Verify and guarantee temperature compensation |
| Conductivity Measurement Range | 0.01% IACS (0.0000010 mm²/m) |
| Corresponding Conductivity | 0.02 in (0.5 mm) |
| Distinguishing Rate | 32 °F (0 °C) to 122 °F (50 °C) |
| Measuring Accuracy | ±0.1% to ±0.5% IACS |
| Temperature Compensation | Automatic compensation to the value of 68 °F (20 °C) |
| Normal Work Environment | |
| Relative Humidity | 0% to 95% |
| Operating Temperature | 32 °F to 122 °F (0 °C to 50 °C) |
| Data Storage | Can store 1000 measurement data |
| Probe 60 KHz | |
| Diameter | 0.47 in (12 mm) |
| Applicable to Minimum Measuring Area Diameter | 0.47 in (12 mm) |
| Probe (120 KHz) | |
| Diameter | 0.31 in (8 mm) |
| Applicable to Minimum Measuring Area Diameter | 0.31 in (8 mm) |
| Measuring Range | 6.9% IACS to 110% IACS (4.0 MS/m to 64 MS/m) |
| Dimensions (L⭑B⭑H) | 7.09 in (180 mm) x 3.15 in (80 mm) x 1.18 in (30 mm) |
| Weight | 0.5 lb (260 g) |
