Features
- Anti-slip impact device handle
- Dustproof USB interface
- 4 function keys for easy operation
- 77-inch (45 mm) color display screen
Technical Specifications
| Hardness Scale | HL, HB, HRB, HRC, HV, HS, σb |
| Measuring Range | 200 HLD to 960 HLD,19.8 HRC to 68.5 HRC, 30 HB to 651 HB, 80HV to 976 HV, 26.4HS to 99.5 HS, 13.5 HRB to 100 HRB, 375 σb to 2639 σb |
| Impact Devices | D type impact device standard, optional C/G/DC/DL/D+15 |
| Accuracy | ±6 HLD (HLD = 800), Repeatability <6 HLD (HLD = 800) |
| Measuring Direction | 360 degree by manual setting |
| Material | Steel, Cast Steel, Stainless Steel, GC IRON, NC IRON, Copper-tin alloy, Cast Aluminum alloy, Macht metal, Brass, Allpoy Tools Steel, Forged Steel |
| Resolution | 1HL, 1HV, 1HB, 0.1 HRB, 0.1 HRC, 0.1 HS |
| Display | High Contrast Segment Liquid Crystal Display (LED Backlight) |
| Memory | 100 groups (each group include 1 to 7 testing result and 1 MEAN value) |
| Communication | USB port (Standard) and Bluetooth (Optional) |
| Power | 2 AA batteries |
| Operating Temperature | 14 °F to 122 °F (-10 ℃ to 50 ℃) |
| Size | 6.02 in x 2.99 in x 1.45 in (153 mm x 76 mm x 37 mm) |
| Weight | 0.61 lb (280 g) include batteries |
