Overview
This Digital Salinity Conductivity Meter has -2 pH to 20 pH range, salinity range of 0.00% to 8.00%, and ±0.2% salinity accuracy.
Features
- LCD display screen, 3.5 inches
- Multi-reading feature allows auto-read, timed-read and continuous-read
- Automatic/Manual temperature compensation ensures accurate results
- Auto-hold feature senses and locks the measurement endpoint
- Data capacity of up to 500 sets for each parameter (GLP-compliant)
- Support for USB communication
- Auto-power off feature effectively extends the battery service life
- Reset feature automatically resumes all settings back to factory default options
- IP65 waterproof
Technical Specifications
| PH | |
| Range | -2.00 pH to 20.00 pH |
| Resolution | 0.1, 0.01 pH |
| Accuracy | ±0.01 pH |
| Calibration Points | Up to 5 |
| Standard Customization | Yes |
| Calibration Reminder | Yes |
| Standard Recognition | NIST, GB and DIN buffers |
| Slope Limit | Yes |
| MV | |
| Range | -2000.0 mV to 2000.0 mV |
| Resolution | 0.1 mV |
| Accuracy | ±0.3 mV or ±0.1% |
| PX | |
| Range | -2.00 pX to 20.00 pX |
| Resolution | 0.1, 0.01 pX |
| Accuracy | ±0.01 pX (±0.01 pX) |
| ISE | |
| Calibration Points | Up to 5 points |
| ISE | |
| Range | 1 e-9 to 9.999 e9 |
| Units | mol/L, mmol/L, g/L, mg/L, μg/L |
| Resolution | Up to 4 significant digits |
| Accuracy | ±0.5% |
| Calibration Points | Up to 5 |
| Conductivity | |
| Range | 0 μS/cm to 1000 mS/cm |
| Resolution | 0.001 μS/cm minimum, various with range selection |
| Accuracy | ±1.0% FS |
| Calibration Points | Up to 3 |
| Standard Recognition | 84 μS/cm, 1413 μS/cm, 12.88 mS/cm |
| Resistivity | |
| Range | 5.00 Ω·cm to 20.00 MΩ·cm |
| Resolution | 0.01 Ω·cm minimum |
| Accuracy | ±1.0% FS |
| TDS | |
| Range | 0.00 mg/L to 300 g/L |
| Resolution | 0.01 mg/L minimum, 3 significant digits |
| Accuracy | ±1.0% |
| Salinity | |
| Range | 0.00% to 8.00% |
| Resolution | 0.01% |
| Accuracy | ±0.2% |
| Saturation | |
| Range | (0.0% to 300.0% |
| Resolution | 0.10% |
| Accuracy | ±2.0% |
| Temperature | |
| Unit | (°C) °F |
| Resolution | 0.1 |
| Relative Accuracy | ±0.2 |
| Measurement | |
| Reading Mode | Auto-Read (Fast, Medium, Slow), Timed, Continuous |
| Reading Prompts | Reading, Stable, Locked |
| Temp. C | ATC, MTC |
| Data Management | |
| Data Storage | 1000 Groups |
| GLP Features | Yes |
| PH Electrode | BNC(Q9) |
| DO With Temp. Probe | 4-pin aviation connector |
| Conductivity With Temp. Probe | 5-pin aviation connector |
| USB | PC, printer |
| Backlight | Yes |
| Auto Shutdown | 300 sec, 600 sec, 1200 sec, 1800 sec, 3600 sec., off |
| IP Rating | IP 65 |
| Date and Time | Yes |
| Power | Rechargeable Lithium battery, AC Adapter, 100 V to 240 V AC input, DC 5 V output |
| Temperature Range | 23.0 ºF to 230 ºF (-5 ºC to 110 ºC) |
| Conductivity Reference Temperature | 68 °F, 77 °F (20 ºC, 25 ºC) |
| Dimensions | 3.54 in × 10.03 in × 1.57 in (90 mm x 255 mm x 40 mm) |
| Weight | 1.1 lb (500 g) |
