Features
- Measurement with basic accuracy of 0.02%
- Output with basic accuracy of 0.05%. 5 digits display for measured value
- Measurements DC current, DC voltage
- Provides 24 V loop voltage and measuring current simultaneously
- Analogue output DC current and simulating transmitter
- Providing loop voltage supply of 24 V
- Current displayed in Am and Am% format
- The step, zero and full output provided with a fast operation.
- Output signal generates an auto ramp current output 4 mA to 20 mA
- The step, zero and full output provided with a fast operation
- Adjustable output gain
- Built-in self-tests with closed-case calibration, no internal calibration adjustment
Technical Specifications
| Measurement | DC voltage | Range 30 V Resolution 0.001 V Basic accuracy 0.02%+2dgt |
| DC current | Range 30 mA Resolution 0.001 mA Basic accuracy 0.0%+4 | |
| Source | DC current | Range 22 mA Resolution 0.001 mA Basic accuracy 0.05%+4dgt |
| Loop power | 24 V | |
| Power Supply | 2 × 1.5 V AA Alkaline battery | |
| Size | 7.09 in x 3.54 in x 1.85 in (180 mm × 90 mm × 47 mm) | |
| Weight | About 1.10 lb (500 g) | |
