Technical Specifications
| Working Voltage | 3.7 V (Lithium battery) |
| Working Method | Touch screen |
| Branch Grounding Resistance Range | 0 kΩ to 999 kΩ (Factory default: 300 kΩ) |
| Branch Grounding Resistance Accuracy | 0 kΩ to 150 KΩ: ≤ 10% ± 2 kΩ 0 kΩ to 150 KΩ: ≤ 10% ± 2 kΩ 150 kΩ to 999 kΩ: Display specific value |
| Ground Resistance Measurement Resolution | 0.1 KΩ |
| Leakage Current Detection Sensitivity | ≤0.1 uA |
| Measurement Accuracy | 100% |
| Alarm Mode | Graphics, data, grounding direction |
| Voice Alarm | Grounding, mutual channeling, measured value, fault direction |
| Waveform Display | Standard sine wave (similar to oscilloscope) |
| Pliers Judgment | Automatic identification of large and small pliers, opening and closing state |
| Continuous Working Time | More than 10 h |
| Working Power Supply | Lithium battery (3.7 V, 4000 mAh rechargeable) |
| Suitable Temperature | 14 ℉ to122 ℉ (-10 ℃ to +50 ℃) |
| Dimensions (Length × Width × Height) | 7.08 in × 3.93 in × 1.57 in (180 mm × 100 mm × 40 mm) |
| Weight | 3.30 lb (1.5 kg) |
