| Detection Method | Diffusion / Suction |
| Data Transmission | RS485 Modbus/4G LTE Optional |
| Preheat Time | 90 Seconds |
| Temperature/ Humidity | -4 to 122 -20 ℃ to 50 ℃)/10% RH to 95% RH (No Condensation) |
| Power Supply/Consumption | AC 220 V/ 50 Hz/ Optional Solar Power Supply / 80 W |
| The Main Material | Cold Rolled Steel Plate |
| Installation Method | Outdoor Column Installation |
| Protection Class | IP 53 |
| Measuring Range | 0 μg/m3 to 2000 μg/m3 |
| Sampling Cutter | Cyclone Physical Cutter |
| Sampling Time | Adjustable, Default Five Minutes |
| Resolution | 1ug/m3 |
| Sampling Mode | Suction Type |
| Air Intake Heating | Heating And Dehumidifying According to Air Humidity |
| Malfunction Alarm | Real-Time Display of Fault Alarms |
| Zero Method | Automatic zero calibration |
| Size | 24.41 in x 17.32 in x 6.30 in (620 mm x 440 mm x 160 mm) |
