| Display mode | Industrial LCD touch screen (XP operating platform) |
| Storage | Fixed 8 g |
| The test method | Low pressure pulse method, multiple pulse method, flash lightning flow method |
| Mode of operation | Double operation, touch pen and mouse operation |
| The test distance | No less than 37.28 mi (60 km) |
| Shortest test distance (blind area) | 0 ft to 16.4 ft (0 m to 5 m) or no blind spots |
| Precise point error | ±0.65 ft (0.2 m) |
| Test error | The systematic error is less than ±1% |
| Multiple pulse generator | Impulse voltage ≤40 kV |
| The resolution of the | V/FM.V is the transmission velocity m/s; Software cursor 0.32 ft (0.10 m) |
| Instrument sampling frequency | 6.25 MHz, 12.5 MHz, 25 MHz, 50 MHz, 100 MHz |
| Power and power consumption | AC 220 V ±10%; Not more than 15 W; DC 12 V (7 AH); No more than 20 W |
| Standby time | It can be used continuously for about 6 hrs |
| The environment temperature | 14 °F to 104 °F (-10 ℃ to 40 ℃) |
| The temperature | -4 °F to +104 °F (-20 ℃ to +40 ℃) |
| Relative humidity | ≤80% |
| Overall dimensions | 7.09 in × 11.81 in × 15.75 in (180 mm × 300 mm × 400 mm) |
| The host weight | 13.66 lb (6.2 kg) |
