Features
- User friendly dialog interactive helps operations like Calibration, making curves, etc.
- All tools you need: DAC, AVG, color Bscan, AWS, etc
- Pulse Repeatition Frequency: 20-3000Hz precise adjust, high speed scan, no miss out
- High Signal to noise ratio, clear and stable echo, anti-noise design, perfect for tough working conditions
- 12-digit AD, high speed sampling leads to better echo diagram with all details. Sensitive and can detect even tiny flaws
- Crystal clear true-color display. Helpful user interface makes the operation much easier
- High speed real-time flaw detection video recording. Unlimited USB data storage
- Blue tooth connection to mobile device to generate and print detection reports on-site
- IP65 standard. Alloy + Silica gel case, water and dust proof, solid and lasts forever
- Damping support makes it stands in any angle
- Battery lasts 15 hours for one charge.
- Each battery has own charging control so with two batteries it can work around the clock
Technical Specifications
| Range | 0 in to 590.6 in (0 mm to 15000 mm), at steel velocity |
| Material Velocity | 100 m/s to 20000 m/s |
| Pulse Repetition Frequency | 20 Hz to 3000 Hz |
| Dynamic range | ≥ 38 dB |
| Resolving Power | > 40 dB (5P14) |
| Sensitivity Leavings | > 66 dB |
| Bandwidth (Amplifier Bandpass) | 0.2 MHz to 35 MHz |
| Power Requirements | AC Mains 100 V to 240 V AC, 50 Hz to 60 Hz |
| Pulse Energy | 200 V, 300 V, 400 V, 500 V selectable |
| Dimensions | 10.2 in x 6.9 in x 2.4 in (260 mm × 175 mm × 60 mm) |
| Operating Temperature | 14 °F to 122 °F (-10 ℃ to 50 ℃) |
| Storage Temperature | -22 °F to 122 °F (-30 ℃ to 50 ℃) |
| Weight | 2.65 lbs. (1.2 kg) |
