| Detected Principle | Electrochemistry |
| Measure Range | 0 to 100 ppm, 0 to 500 ppm, 0 to 1000 ppm, 0 to 2000 ppm, 0 to 5000 ppm |
| Resolution | 0.01 ppm,0.1 ppm,1 ppm |
| Precision | ≤ ± 2% F.S (Higher measure range can be customized) |
| Pump Fow Rate | Flow rate range: 0 to 800 mL/Min |
| Display Screen | 2.4-inch color display, resolution 320 x 240 resolution |
| Display Contents | Gas molecular formula, concentration, unit, pump status, etc |
| Alarm | buzzer, alarm status prompt on the display |
| Data Logging | Independent SD memory card, automatic measurement of measurement data, customizable recording interval |
| Communication And Data Download | It can be directly connected to the computer via USB to quickly download the TXT file for storing data; with the PC software to download, store, analyze and print the data. |
| Power Supply | 12 to 36 VDC |
| Wireless Network | Built-in module to upload data to the network platform, regardless of distance (optional) |
| Network Frequency | 2.4 G high frequency |
| Installation Method | Wall-mounted, pipe-flow type (optional) |
| Language | Chinese or English |
| Humidity | 0 to 95% RH (no condensation) (optional filtration device can be equipped if in hyperhumidic ares ) |
| Explosion-Proof | Ex d IIC T6 Gb |
| Protection Degree | IP65 |
| Temperature | -4 °F to 122 °F (-20 ºC to 50 ºC) |
| Weight | 6.61 Ib (3 kg) |
| Size | 12.59 in x 9.05 in x 4.33 in (320 mm x 230 mm x 110 mm) |
