Features
- Support For OEM or ODM or OBM
- Wireless Network Data Transmission
- Real Time Monitoring 24 Hours A Day
- Flexible Selection of System Configuration
- Independent Environmental Monitoring Station
Technical Specifications
| Detection Method | Diffusion or Suction |
| Data Transmission | RS485 Modbus or 4G LTE Optional |
| Preheat Time | 90 Seconds |
| Particulate Matter Type | PM 2.5 or PM 10 or TSP |
| Power Supply | AC 110 to AC 230 V or Solar energy |
| Installation Method | Standing pole mounted |
| Gas Type | O3 or SO2 or NO2 or CO |
| Gas Optional | H2S or NH3 or TVOC |
| Data Transmission | RS485 MODBUS OR 4G LTE |
| Power Supply Or Consumption | AC 220 V or 50 Hz or Optional Solar Power Supply or 80 W（MAX） |
| The Main Material | Cold Rolled Steel Plate |
| Installation Method | Outdoor Column Installation |
| Protection Class | IP53 |
| Size | 24.4 in × 17.32 in × 6.29 in (620 mm × 440 mm × 160 mm) |
| Temperature or Humidity | -4 F to 122 F (-20 ℃ to 50 ℃) or 10% RH to 95% RH (No Condensation) |
