Overview
This 4 channel mini digital oscilloscope is ideal for common electronic engineering tasks. It is based on ARM cortex M3 (STM32F103VCT6) 32 bit platform and provides a real-time sampling rate of 72 MSa/s with integrated FPGA and high speed ADC. It performs waveform storage and playback. It has an internal 2 MB USB disk to store waveforms, user applications and for firmware upgrades. Scheme and source files are also open for application development.
Key Features
- Portable and lightweight
- Firmware upgrade
- Waveform storage and playback
- Open Source
- High performance, 72 MSa/s real-time sampling rate
- 4 programmable space for user application program 32 standard or built-in waveforms
Technical Specifications
| Display | Full Color 3″ TFT LCD 400 × 240 |
| Input Channel | Analog: CH(A)/CH(B) |
| Digital: CH(C)/CH(D) | |
| Max Sample Rate | 72 MSa/s, 8 bit |
| Sample Memory Depth | 4096 points for each channel |
| Vertical Scale | 20 mV to 10 V/div(xl probe) |
| Vertical Resolution | 8 bit |
| Horizontal Sensitivity | 0.1 us/Div to 1 s/Div |
| Horizontal Position | Adjustable |
| Input Coupling | AC/DC |
| Input Impedance | > 800 kΩ |
| Max Input Voltage | 80 Vpp (xl probe) |
| Trigger Type | Auto, Normal, Single, SCAN, None |
| Trigger Source | CH1/CH2/EXT |
| Signal Generator | Sine/Triangle/Saw/Square,10 Hz to 20 kHz |
| Storage | Internal 2 MB USB disk, BMP, DAT file |
| Auto Measure | Max, Min, Vbt, FPS, Vpp, Vdc, RMS |
| Sampling Mode | Real time |
| Dimension | 98 mm × 60 mm × 14.5 mm |
| Weight | 80 g (without battery) |
| Accessories | 2 mcx oscilloscope probe/battery |
