Overview
Enviro Test Construct Commercial-Grade Hybrid Solar Inverter is a reliable and efficient solution for residential and small-scale solar systems. This device delivers pure sine wave output, ensuring stable and safe power for sensitive appliances. It supports both grid electricity and battery power, with priorities sexibility to set priority based on user needs.Equipped with a bypass charging function, this product allows AC charging even when switched off. With a wide AC input voltage range of 90 to 280V and high charging current adjustment, it ensures adaptability in diverse energy conditions. This inverter also communicates seamlessly with compatible MPPT charge controllers, offering optimized solar energy management.Designed with intelligent protection mechanisms, this device guarantees enhanced security against overload, short-circuit, and other operational risks. Compact in size yet powerful in performance, it provides dependable energy for households, off-grid applications, and backup power requirements.
Features
- Pure sine wave output for stable and efficient performance
- Wide input voltage range: 90V to 280V AC
- AC and battery power priority selectable
- Intelligent protection system for enhanced safety
- High charging current with adjustable settings
- Supports communication with MPPT charge controller
- Cold start capability for reliable operation
- ≥95% efficiency in line mode (with fully charged battery)
- Compact design for easy installation
- Available in multiple power capacities (1500VA to 10000VA)
Technical Specifications
| Rated Output Power (VA) | 1500 VA, 2500 VA, 3500 VA, 5000 VA, 7500 VA, 10000 VA |
| Rated Output Power (W) | 1200 W, 2000 W, 1600 W, 2800 W, 4000 W, 6000 W, 8000 W |
| Nominal DC Input Voltage | 12 V, 24 V, 48 V |
| Input Voltage Waveform | Sinusoidal (Utility or generator) |
| Nominal Input Voltage | 220 Vac |
| Nominal Input Frequency | 50 Hz or 60 Hz |
| Output Voltage Waveform | Same as Input Waveform |
| Efficiency (Line Mode) | ≥ 95% (Rated R load and battery fully charged) |
| Pass Through Without Battery | No |
| Max Bypass Overload Current | AC 30 A or AC 63 A |
| Inverter Output Voltage Waveform | Pure Sine Wave |
| Peak Efficiency | 90% |
| Capable of Starting Electric Loads | Yes |
| Output Short Circuit Protection | Yes |
| Cold Start Voltage | 11.5 V, 23 V, 46 V |
| Operating Temperature | 32 °F to 104 °F (0 °C to 40 °C) |
| Storage Temperature | 5 °F to 140 °F (-15 °C to 60 °C) |
| Net Weight | 20.5 lb (9.3 kg), 46.3 lb (21.0 kg), 45.6 lb (20.7 kg), 57.3 lb (26.0 kg), 57.1 lb (25.9 kg), 64.2 lb (29.1 kg), 123.0 lb (55.8 kg) |
| Product Size (D x W x H) | 10.0 in x 9.4 in x 5.7 in (254 mm x 238 mm x 145 mm)18.6 in x 11.5 in x 7.7 in (472 mm x 291 mm x 195 mm)20.7 in x 16.5 in x 7.7 in (525 mm x 420 mm x 195 mm)24.2 in x 16.5 in x 7.7 in (615 mm x 420 mm x 195 mm) |
