Key Features
- Large LCD display
- Easy to switch between gas concentration unit of PPM and mg/m3
- Ultra-high buzzer alarm sound, higher and lower alarm values are settable
- Data storage function
- Data export to PC via USB connection
- Two target point calibration which both can be set up and supports automatic zero point calibration
- Rechargeable lithium polymer batteries with a capacity of 1800 mA
- Strong and upscale alligator clip, portable
- Strong, durable and reliable
- Battery of working time more than 50 hours
Technical Specifications
| Principle of Detection | Catalytic combustion |
| Range of Measurement | 0-100%LEL |
| Resolution | 1%LEL |
| Precision | 3%FS |
| Sampling Method: | diffusion (add external sampling pump if necessary) |
| Unit of Concentration: | one press to switch between ppm and mg/m3, system will finish conversion of values automatically |
| Display Technology | Monochrome dot matrix 128 * 128 LCD graphic display |
| Battery | 3.7 V rechargeable lithium battery, with capacity of 1800 mA |
| Charger | Travel charger with USB |
| Explosion-proof Grade | Exia?CT4 |
| Protection Grade | IP66 |
| Working Temperature | -20?~50? or -4~122 oF |
| Working Humidity | 0-95%RH |
| Housing Material | ABS+PC |
| Dimensions | 155 * 78 * 35 mm or 6.1*3.1*1.4 inch |
| Weight | 300 g |
