Technical Specifications
| Diameter | DN 0.5 in to 236.2 in (15 mm to 6000 mm) |
| Accuracy | Better than ± 1% |
| Repeatability | Better than 0.2% |
| Principle | Transit-time measuring principle |
| Flow range | 0.1 m per second to 8 m per second |
| Display | LCD, instantaneous flow, positive and negative cumulative flow, flow rate |
| Input | Three analogue 4 mA to 20 mA can connect 3-wired heat transducers PT100 to measure heat |
| Medium | Sea water |
| Power supply | DC 8 V to 36 V or AC 85 V to 264 V |
| Wire length | 16.4 ft (5 m) |
| Output | 4 mA to 20 mA, MODBUS-RS485 |
| Power dissipation | 1.5 W |
| Medium temperature | -22 °F to 194 °F (-30 °C to 90 °C) |
